Features:
Conductor: Tin copper, 10+10/0.10mm or 10+20/0.10mm, 28AWG
Insulation: PVC
Color: Black/White/other color
Thickness: 0.4mm,
Diameter: 1.0±0.1mm
Shield: Tin copper ,10/0.10mm or 20/0.10mm
Jacket: PVC, Non migration against ABS, Lead free
Length: 1.2m and other length are available
Electrical:
Testing: 100% open & short test
Contact Resistance: 30 MΩ Max
Voltage rating: AC/DC 125V
Current rating: AC/DC 1A
Withstanding Voltage: AC 250V/1 min
Insulation resistance: 100 MΩ Min
Working Temperature: -25~+85
Mechanical:
Insertion Force: 35 N Max
Withdraw Force: 10 N Min
